Rim Drive Technology electric outboards .5kW - 10kW
Electric sailing is the future
Environmentally friendly, high quality and silent
The worldwide manufacture for electric rim drive motors – Rim Drive Technology believes in offering the total solution for every client within every market: from electric motor to battery, from throttle control to battery monitor.
A rim drive motor has some specific advantages over other electric motors:
- Very little chance to seize your propeller due to axle less design
- No wearing parts within the motor
- Completely water lubricated
- No oil used anywhere within the motor
- Compact design
- Lightweight
- Quick response time
- High efficiency
- Only one rotating motor part
- Only salt water resistant materials used
- Integrated motor controller
- Safe operation by means of a kill switch
- Clear user interface with LED
- Different trim settings
BATTERIES
Our LiFePO4 batteries offer one of the lowest prices per Watt-hour available.
12V, 24V, 48V, 96V battery packs
High energy density,
Minimal dimensions,
Lightweight,
Safe,
Reliable,
Maintainance free,
User friendly,
Long life,
High discharge capacity,
Works with all rim drives
OUTBOARDS:
One year warranty for non-commercial use
Integrated motor controller
LED user interface
5 trim settings
Salt water resistant
Universal battery connector
Includes 0.5 m battery cable
- Listing ID: 17072
- Price: Various prices per model, starting at €7,400. Please contact us
- Condition: New - In Stock
- Motor Type: Outboard
- Motor Manufacturer: Rim Drive Technology
- Output power: 0.5 kW, 3kW, 5kW - 11 kW (HP)
- Comparable gas/petrol HP: 1HP, 6.5HP, 10HP, 20HP
- Motor Efficiency: 90%+
- Shaft Length: 67cm - 86.2cm
- Propeller: Propeller Diameters: 65mm, 86mm, 133mm, 212mm
- Motor Weight: 2.5kg, 3.5kg, 5kg, 14kg
- Tilt: Manual
- Tilt/Trim More Info: 5 tilt positions
- Cooling: Passive Water
- Voltage: all models 48V
- Amps/Current: 11A, 63A, 104A, 230A
- Battery Capacity: 12V, 24V, 48V, 96V battery packs available
- Cables: Included
- Battery Monitor: Yes
